IEP Bimed ARIES Couplers for Ex d/e Applications

IEPBIMEDARIES

RM 53.70

IEP BIMED Gaskets (Washers)

IEPBIMED-GASKETS-WASHERS

RM 14.10

IEP BTEPG, P/N: BNTC-7110R, Remote control battery operated hydraulic cutting tool c/w Lithium-ion battery x 1 pc 18V 5Ah, Battery charger voltage 100-240V 50/60 Hz c/w 3 pin UK plug x 1, Romote controller x 1, Carrying case x 1 (Set) Cutting capacity: Armored cable below Φ110mm Dimensions:631×338×95 mm Weight:11 kg Power supply: Lithium battery 18V 5.0Ah

BNTC-7110R

RM 10,967.00

IEP Tianze P/N: B45-TC8 c/w 45 Deg cutting angle blade, Battery Operated Hydraulic Cutting Tool, Scope of application: Suitable for cutting steel bars, steel cables, bolts and padlocks etc within 8mm diameter, Small curter head curve type c/w Lithium-ion battery x 1 pc 18V 2.5Ah--Battery charger voltage 100-240V 50/60 Hz c/w 3 pin UK plug x 1--Carrying case x 1 (Set) Cutting force: 45kN Cutting time: 2 seconds (depending on material thickness and hardness) Dimension: 345mm×112mm×75mm Weight: 2.2

B45-TC8

RM 6,441.70

IEP Tianze P/N: B50-60UNV, Battery operated hydraulic universal tool c/w Lithium-ion battery x 1 pc 18V 5Ah, Battery charger voltage 100-240V 50/60 Hz c/w 3 pin UK plug x 1, Carrying case x 1 (Set) Crimping range: 300 mm² Copper lugs and connectors 240 mm² Aluminium lugs and connectors Cutting range: Max Ф24 mm Copper or Aluminium cable Max 240 mm² ACSR Output force: 60 kN/6T Dimensions: 455x125x89mm Battery: 18V 5Ah

B50-60UNV

RM 6,854.40

IEP Tianze P/N: BHP-P18, Intelligent Rechargable Hydraulic Pump (set), Operating voltage: DC 18V Operating pressure:70MPa High pressure flow: 0.3L/min Low pressure flow: 1L/min Oil tank capacity:1L Remote control distance ≤30m Data transfer: 4G Abnormal operation alarm Low battery warning High temperature warning and protection Maintenance tips Weight 4.9kg Level of protection IP54

BHP-P18

RM 9,745.50

IEP Tianze P/N: MC-616B, Battery Operated Crimping Tool c/w Lithium-ion battery x 1 pc 18V 2Ah, Battery charger voltage 100-240V 50/60 Hz c/w 3 pin UK plug x 1, Carrying case x 1 (Set) Crimping capacity: 0.14 to 50mm cable lugs and connectors Battery: 18V 2AH; Weight:1.75kg Dimension: 253x110x62mm

MC-616B

RM 4,265.00

IEP Tianze P/N: NBMC-50ML, Battery operated cutting tool - Ratchet mechanism c/w Lithium-ion battery x 1 pc 18V 2Ah, Battery charger voltage 100-240V 50/60 Hz c/w 3 pin UK plug x 1, Carrying case x 1 (Set) Crimping capacity: 0.14 to 50mm cable lugs and connectors Battery: 18V 2AH Weight:0.98kg Dimension: 253x110x62mm

NBMC-50ML

RM 3,198.70

IEP Tianze P/N: RHC-130DM, Hydraulic Crimping Head (Set), Crimping force: 130 kN Crimping range.CU/Al lugs and splices 400mm Dimensions:150x105x285mm Weight:9 kg Operating pressure.70 Mpa

RHC-130DM

RM 2,924.50

IEP Tianze, P/N: GBC-713H, Die-free intelligent battery operated hydraulic crimping tool c/w Lithium-ion battery x 1 pc 18V 5Ah, Battery charger voltage 100-240V 50/60 Hz c/w 3 pin UK plug x 1, Carrying case x 1 (Set) Crimping capacity : Crimping 10 to 300mm² copper terminaland 10 to 240mm² aluminum terminal,and connecting tubes of the same specifications Crimping force: 130kN/13T System pressure: 75MPa Dimensions: 446x336x91 mm Weight: 9.8kg (Exclude battery)

GBC-713H

RM 12,185.60
